Knipex Electronic Super Knips® 125mm Fine Wire Cutting Pliers 78 61 125

KNIPEX Electronic Super Knips® 125mm Fine Wire Cutting Pliers 78 61 125

78 61 125 Electronic Super Knips®
Precision pliers for ultra fine cutting work, e. g. in electronics and fine mechanics. Ground, very sharp cutting edges without bevel. Precisely shaped tips cut wires close to a surface from Ø 0.2 mm. Shear cut with controlled micro cutting edge misalignment for the most precise cutting of even the thinnest of wires and for a long service life. Joint with stainless steel rivet. Extremely smooth movement for minimum operator fatigue. With opening spring and opening limiter. also suitable for cutting fibre optic cable. cutting edges additionally induction-hardened, cutting edge hardness approx. 62 HRC. Special tool steel, oil hardened in multiple stages.

Cutting capacities medium hard wire (diameter): Ø 1.2 mm

Cutting capacities soft wire (diameter): Ø 0.2 – 1.6 mm

Jaw length (B): 9 mm

Jaw thickness (joint) (D): 7.5 mm

Head width (A): 13.5 mm

Technical Information:

• also suitable for cutting fibre optic cable
• cutting edges additionally induction-hardened, cutting edge hardness approx. 62 HRC
• extremely smooth movement for minimum operator fatigue
• ground, very sharp cutting edges without bevel
• Joint with stainless steel rivet
• Precisely shaped tips cut wires close to a surface from Ø 0.2 mm
• precision pliers for ultra fine cutting work, e. g. in electronics and fine mechanics
• Shear cut with controlled micro cutting edge misalignment for the most precise cutting of even the thinnest of wires and for a long service life
• Special tool steel, oil hardened in multiple stages
• with opening spring and opening limiter

Downloadable Files:

• Data Sheet: View Here
