Sealey Air Compressor 150L Belt Drive Petrol Engine 6.5hp

Sealey 150L Belt Drive Air Compressor with Petrol Engine 6.5hp

Air Displacement: 20.9cfm(591L/min).

Maximum Free Air Delivery: 15.2cfm(430L/min).

Maximum Pressure: 145psi(10bar).

Static compressor with Honda GX200 6.5hp unit coupled to heavy-duty, 2-stage twin piston, cast iron pump.

Pump has heavy-duty full cast cylinders, capped by alloy heads for improved heat dissipation and long-life.

Heavy-duty drive guard protects belt and flywheel that is designed to also force air over the pump to aid cooling.

Supplied with full CE certification, test certificates and operating/maintenance manual.

Features gauge and air outlet.

Runs on unleaded fuel.

This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.

Specification:

• Model No SA1565
• Air Displacement cfm(L/min): 20.9(591)
• Brand: Sealey
• Maximum Free Air Delivery cfm(L/min): 15.2(430)
• Maximum Pressure: 145psi(10bar)
• Motor Output: 6.5hp
• Motor Type: Honda GX200 Petrol
• Nett Weight: 103kg
• Noise Level: 97dB(A)
• Oil Capacity: 1.2L
• Outlet: 1/2"BSP Female Tap
• Receiver Capacity: 150L
• Size (W x D x H): 1360 x 540 x 1110mm

Product Guarantee: 1 Year
Catalogue Page: Page 1185

Downloadable Files:

• Instructions: View Here
• Material Safety Data Sheet: View Here
• Parts Diagram: View Here
